Crude cooking oil refining machine manufacturer
Batch Type Edible Oil Refinery / Chat on line / Give me a price / Date:Nov 06, 2017
After edible oil pressing process or edible oil extraction process, we get crude oil. However, the crude oil can’t eat and sell to the market. The crude edible oil must be processed with cooking oil refining machine .
Cooking oil refining machine is through take off impurity, degumming, decoloring, deodorization, removeing wax, fractionation etc, to achieve different standards edible oil. Crude cooking oil refining machine is suitable for refining various crude vegetable oil, such as sunflower seed oil, tea seed oil, groundnut oil, cottonseed oil, palm oil, rice bran oil, soybean oil, corn oil and palm oil, etc.
Various kinds of oil seeds
The cooking oil refining machine process consists of following section:
1.Neutralizing Section
First stage of crude cooking oil refining machine is to remove Free Fatty Acids (F.F.A.) with caustic soda treatment called Neutralizing Process, thereafter further processed in the bleaching section under vacuum & treated with bleaching earth & activated carbon for removing colour. Finally it will be deodorized under high vacuum and high temperature to remove the odour from the oil.
2.Bleaching Section
The Oil received from previous stages contains traces of soap, iron and few ppm of Phospholipids and Carotenes. These contents are undesirable and required to be removed in Bleaching Operation, Doing's Steam Agitated Bleacher comprises of an acid treatment, a separate Oil and Earth Mixing Device with Mechanical Mixer (this arrangement ensures no carryover of bleaching earth into vacuum system), main bleaching vessel and Hermetic Filters.
3.Deodorizing Section.
Physical Refining process is used to remove FFA (Free Fatty Acid), using Steam Distillation method at high temperature and under high vacuum and it is followed by Deodorization and an extra technical facility is added before deodorisation for removal of free fatty acid.
Deodorization process in crude cooking oil refining machine is used to remove unacceptable odour by Steam Distillation, the Odoriferous Compound are strip off with the help of live injected steam into heated oil under high vacuum.
Cooking oil refining machine
In general, Crude cooking oil refining machine is divided into 3 types, batch type cooking oil refining machine, semi-continuous cooking oil refining machine, continuous cooking oil refining machine, the difference of which is capacity. If you capacity is 1t-30tpd,you can choose batch type cooking oil refining machine; If you capacity is 20t-50tpd,you can choose semi-continuous cooking oil refining machine; If you capacity is 50t-200tpd,you can choose continuous cooking oil refining machine. What’s more, Our engineers can help you design and install cooking oil refining machine according to your capacity and requirements. If you want to know more about cooking oil refining machine, please feel free to contact us.
Cooking oil refining machine is through take off impurity, degumming, decoloring, deodorization, removeing wax, fractionation etc, to achieve different standards edible oil. Crude cooking oil refining machine is suitable for refining various crude vegetable oil, such as sunflower seed oil, tea seed oil, groundnut oil, cottonseed oil, palm oil, rice bran oil, soybean oil, corn oil and palm oil, etc.
Various kinds of oil seeds
1.Neutralizing Section
First stage of crude cooking oil refining machine is to remove Free Fatty Acids (F.F.A.) with caustic soda treatment called Neutralizing Process, thereafter further processed in the bleaching section under vacuum & treated with bleaching earth & activated carbon for removing colour. Finally it will be deodorized under high vacuum and high temperature to remove the odour from the oil.
2.Bleaching Section
The Oil received from previous stages contains traces of soap, iron and few ppm of Phospholipids and Carotenes. These contents are undesirable and required to be removed in Bleaching Operation, Doing's Steam Agitated Bleacher comprises of an acid treatment, a separate Oil and Earth Mixing Device with Mechanical Mixer (this arrangement ensures no carryover of bleaching earth into vacuum system), main bleaching vessel and Hermetic Filters.
3.Deodorizing Section.
Physical Refining process is used to remove FFA (Free Fatty Acid), using Steam Distillation method at high temperature and under high vacuum and it is followed by Deodorization and an extra technical facility is added before deodorisation for removal of free fatty acid.
Deodorization process in crude cooking oil refining machine is used to remove unacceptable odour by Steam Distillation, the Odoriferous Compound are strip off with the help of live injected steam into heated oil under high vacuum.
Cooking oil refining machine
